High Speed GTC Flat Flame Natural Gas Furnace Burner Factory Directly For Stainless Steel Boiler Manufacturing Plants Aluminum Shell
- Power Range：30-5000kW
- Suitable for d rying equipment, hot a ir furnace, aluminum melting furnace, roller kiln, tunnel kiln, trolley furnace, baking oven and other industrial furnaces.
- Widely used in many combustion heating devices in industries such as s teel, heat treatment,n on-ferrous metals, forging, glass, ceramics, textiles and food processing.
- Installation method: can be installed on the top or side wall.
- Overview
- Recommended Products
- Combustion power range is 30-5000kW, forced air supply type gas burner.
- GT is aluminum shell, GB is cast iron shell, ZB is steel welded shell.
- Heat-resistant steel combustion tube can be used with burner bricks or ceramic silicon carbide combustion tube.
- Flame type (optional): long flame, medium flame, short flame, flat flame.
- Spray speed: low speed, medium speed, high speed, up to 150m/s.
-
Applicable gas types: natural gas, liquefied gas, coke oven gas, mixed city gas, low calorific value gas and combustible industrial exhaust gas, etc.Wide adjustment ratio, high combustion efficiency, no backfire and flame out.
- Installation method: can be installed on the top or side wall.
- Direct ignition is used for power within 1000kW.
- Flame monitoring can be used with ion microprobe or UV sensor.
GTC/GTO series
Nozzle block that equiped with nozzle, R type nozzle head: There is 6" inclination angle in the nozzle block hole; H type nozzle head: The inner
hole of the nozzle block is a cylinder, and the inner hole length is 3 times of the inner diameter(3X d).
2. If you require for burner nozzle with higher power, please contact us.
3. The diameter of the flame is generally 1-2 times the diameter of the outlet of the nozzle tube or the burner block.
Application：
-Suitable for drying equipment, hot air furnace, aluminum melting furnace, roller kiln, tunnel kiln, trolley furnace, baking oven and other industrial furnaces.
-Widely used in many combustion heating devices in industries such as steel, heat treatment, non-ferrous metals, forging, glass, ceramics, textiles and food processing.
